MUTAI 100A MCCB Adjustable Molded Case Circuit Breaker

Short Description:

The CMTM1adjustable molded case circuit breaker is a newly upgraded circuit breaker developed by the company. It was designed by combining the advantages of similar international products with the demands of both domestic and international markets. This MCCB is primarily used for distributing electric power energy, protecting circuits and power equipment from overload, short circuit, and undervoltage. It is also suitable for line conversion and infrequent motor starting.

Send email to us

Product Detail

Product Tags

Product Details

The CMTM1 adjustable molded case circuit breaker is a newly upgraded circuit breaker developed by the company. It was designed by combining the advantages of similar international products with the demands of both domestic and international markets. This MCCB is primarily used for distributing electric power energy, protecting circuits and power equipment from overload, short circuit, and undervoltage. It is also suitable for line conversion and infrequent motor starting.

Model NO.		CMTM1-150
Poles		3
Current (A) In		16,25,40,63,100,150
Delay adjustment（Ir1）In		10-16，20-25，32-40，50-63，80-100，125-150
Instantaneous adjustment（Ir3）In		/
Standard		IEC 60947-2 GB/T 14048.2
Standard test temperature		50℃
Ue (V)		400
Ui (V)		800
Uimp (kV)		8
Icu (kA)		25
Ics (kA)		15
Mechnical life time		15000
Electric life time		10000
